mbedtls tls 客户端应用详解

介绍 mbedtls 的 tls client 的使用方法，常见的功能参数配置和含义。当前使用的 mbedtls 版本是： mbedtls-3.4.0。

功能参数配置

需要配置的功能选项

设置 tls 协议版本: 配置 tls 1.2, tls 1.3, 还是二者都支持。
认证方式设置：单向认证、双向认证、还是 psk。
握手时的校验等级设置：不校验证书合法性，仅加密；校验，但如果失败也继续执行后面的握手流程；校验不通过则终止握手流程。
服务器ca证书设置
客户端证书和密钥设置
预定义共享密钥设置

编译配置

使用 mbedtls_config.h 配置文件，tls 1.2 默认打开，不需要修改，但 tls 1.3 未开启，需要特别设置。

//mbedtls_config.h

#define MBEDTLS_SSL_PROTO_TLS1_3

#define MBEDTLS_SSL_TLS1_3_COMPATIBILITY_MODE

#define MBEDTLS_USE_PSA_CRYPTO

#define MBEDTLS_PSA_CRYPTO_CONFIG

解决 mps_common.h 中的编译问题，替换 MBEDTLS_MPS_STORED_SIZE_MAX 和 MBEDTLS_MPS_SIZE_MAX 宏定义。

//mps_common.h

#define MBEDTLS_MPS_STORED_SIZE_MAX (SIZE_MAX)

#define MBEDTLS_MPS_SIZE_MAX (SIZE_MAX)

API 设计和实现

接口处理的事情，主要是连接参数配置、打开和关闭连接，接收和发送数据。

数据结构定义：

typedef enum
{
    QTF_TLS_AUTH_MODE_CERT = 0, // 校验证书
    QTF_TLS_AUTH_MODE_PSK, // 预定义共享密钥
    QTF_TLS_AUTH_MODE_MAX
}qtf_tls_auth_mode_t;

typedef enum
{
    QTF_TLS_VERSION_TLS1_2 = 0,     // TLS v1.2
    QTF_TLS_VERSION_TLS1_3,         // TLS v1.3
    QTF_TLS_VERSION_TLS1_2_1_3,     // TLS v1.2 and TLS v1.3
    QTF_TLS_VERSION_MAX
}qtf_tls_version_t;

typedef enum
{
    QTF_TLS_VERIFY_MODE_NONE = 0, // 不校验证书是否合法
    QTF_TLS_VERIFY_MODE_OPTIONAL, // 证书校验失败，继续执行握手
    QTF_TLS_VERIFY_MODE_REQUIRED, // 证书校验失败终止握手，推荐配置
    QTF_TLS_VERIFY_MODE_MAX
}qtf_tls_verify_mode_t;

typedef enum
{
    QTF_TLS_DEBUG_LEVEL_NONE = 0,
    QTF_TLS_DEBUG_LEVEL_ERROR,
    QTF_TLS_DEBUG_LEVEL_STATE,
    QTF_TLS_DEBUG_LEVEL_INFO,
    QTF_TLS_DEBUG_LEVEL_VERBOSE,
}qtf_tls_debug_level_t;

// tls 报文分片大小设置
typedef enum
{
    QTF_TLS_MAX_FRAG_LEN_NO_USE = 0, // 不设置
    QTF_TLS_MAX_FRAG_LEN_512, // 设置 tls 报文分片大小 512 字节
    QTF_TLS_MAX_FRAG_LEN_1024,
    QTF_TLS_MAX_FRAG_LEN_2048,
    QTF_TLS_MAX_FRAG_LEN_4096,
}qtf_tls_max_frag_len_t;

typedef struct
{
    qtf_tls_auth_mode_t auth_mode; // 认证方式
    qtf_tls_verify_mode_t verify_mode; // 握手校验等级
    qtf_tls_version_t tls_version; // tls 协议版本设置
    qtf_tls_debug_level_t debug_level; // 调试日志等级设置
    qtf_tls_max_frag_len_t max_frag_len; // 报文分片大小设置
    uint32_t hanshake_timeout_ms; // 握手超时时间设置
    const char *ca_cert; 	// 服务器ca 证书
    uint32_t ca_cert_len;
    const char *client_cert; // 客户端证书
    uint32_t client_cert_len;
    const char *client_key; // 客户端密钥
    uint32_t client_key_len;
    const char *client_key_passwd;
    uint32_t client_key_passwd_len;
    const char *psk; // 预定义共享密钥
    uint32_t psk_len;
    const char *psk_id;
}qtf_tls_conn_param_t;

typedef enum

{

QTF_TLS_AUTH_MODE_CERT = 0, // 校验证书

QTF_TLS_AUTH_MODE_PSK, // 预定义共享密钥

QTF_TLS_AUTH_MODE_MAX

}qtf_tls_auth_mode_t;

typedef enum

{

QTF_TLS_VERSION_TLS1_2 = 0, // TLS v1.2

QTF_TLS_VERSION_TLS1_3, // TLS v1.3

QTF_TLS_VERSION_TLS1_2_1_3, // TLS v1.2 and TLS v1.3

QTF_TLS_VERSION_MAX

}qtf_tls_version_t;

typedef enum

{

QTF_TLS_VERIFY_MODE_NONE = 0, // 不校验证书是否合法

QTF_TLS_VERIFY_MODE_OPTIONAL, // 证书校验失败，继续执行握手

QTF_TLS_VERIFY_MODE_REQUIRED, // 证书校验失败终止握手，推荐配置

QTF_TLS_VERIFY_MODE_MAX

}qtf_tls_verify_mode_t;

typedef enum

{

QTF_TLS_DEBUG_LEVEL_NONE = 0,

QTF_TLS_DEBUG_LEVEL_ERROR,

QTF_TLS_DEBUG_LEVEL_STATE,

QTF_TLS_DEBUG_LEVEL_INFO,

QTF_TLS_DEBUG_LEVEL_VERBOSE,

}qtf_tls_debug_level_t;

// tls 报文分片大小设置

typedef enum

{

QTF_TLS_MAX_FRAG_LEN_NO_USE = 0, // 不设置

QTF_TLS_MAX_FRAG_LEN_512, // 设置 tls 报文分片大小 512 字节

QTF_TLS_MAX_FRAG_LEN_1024,

QTF_TLS_MAX_FRAG_LEN_2048,

QTF_TLS_MAX_FRAG_LEN_4096,

}qtf_tls_max_frag_len_t;

typedef struct

{

qtf_tls_auth_mode_t auth_mode; // 认证方式

qtf_tls_verify_mode_t verify_mode; // 握手校验等级

qtf_tls_version_t tls_version; // tls 协议版本设置

qtf_tls_debug_level_t debug_level; // 调试日志等级设置

qtf_tls_max_frag_len_t max_frag_len; // 报文分片大小设置

uint32_t hanshake_timeout_ms; // 握手超时时间设置

const char *ca_cert; // 服务器ca 证书

uint32_t ca_cert_len;

const char *client_cert; // 客户端证书

uint32_t client_cert_len;

const char *client_key; // 客户端密钥

uint32_t client_key_len;

const char *client_key_passwd;

uint32_t client_key_passwd_len;

const char *psk; // 预定义共享密钥

uint32_t psk_len;

const char *psk_id;

}qtf_tls_conn_param_t;

连接参数配置说明：

auth_mode：认证方式设置。

一是通过证书认证，另一个是通过预定义密钥 PSK。
verify_mode：握手的校验等级。

推荐配置为 QTF_TLS_VERIFY_MODE_REQUIRED。如果只是想加密而不校验，可以配置 QTF_TLS_VERIFY_MODE_NONE 或 QTF_TLS_VERIFY_MODE_OPTIONAL。
tls_version：tls 协议版本。

推荐配置成 tls 1.2 或 tls 1.3，tls 1.2 以下的版本不安全，tls 1.3 版本 mbedtls 没有完整支持。
debug_level：日志等级。

推荐设置 QTF_TLS_DEBUG_LEVEL_NONE 关闭日志输出。排查问题时可以将日志打开 QTF_TLS_DEBUG_LEVEL_VERBOSE（注意会打印密钥和收发数据的明文内容）。
max_frag_len：数据分片大小设置。

在客户端侧设置，用于协商数据分片大小，设置这个参数应该是出于对使用内存大小和带宽的考虑。

设置太小，可能会出现服务器证书接收不完整导致握手失败问题，但最大值也不能设置超过接收缓冲区的大小。
hanshake_timeout_ms：握手超时时间。
ca_cert：服务器的 ca 证书。

如果要求校验证书，则必须设置。客户端校验服务器是否合法，单向认证。
client_cert：客户端证书。

要求双向认证的时候必须设置，用于服务器校验客户端是否合法。同时还要设置 client_key。
psk ：预定义共享密钥。

psk 不需要证书认证，减少握手数据交互流程，但需要指定 psk_id 身份标识和指定加密套件。

接口定义：

void *qtf_tls_connect(const char *host, uint16_t port, qtf_tls_conn_param_t *param);

int qtf_tls_send(void *handle, const void *buf, uint32_t len, uint32_t timeout_ms);

int qtf_tls_recv(void *handle, void *buf, uint32_t len, uint32_t timeout_ms);

int qtf_tls_close(void *handle);

接口实现:

#include <stdio.h>
#include <stdlib.h>
#include <string.h>

#include "qt_idf_tls.h"
#include "dlg/dlg.h"

#include "mbedtls/net_sockets.h"
#include "mbedtls/ssl.h"
#include "mbedtls/ctr_drbg.h"
#include "mbedtls/debug.h"
#include "mbedtls/platform.h"
#include "mbedtls/timing.h"
#include "mbedtls/entropy.h"
#include "mbedtls/error.h"

typedef struct
{
    mbedtls_net_context      socket_fd;
    mbedtls_entropy_context  entropy;
    mbedtls_ctr_drbg_context ctr_drbg;
    mbedtls_ssl_context      ssl;
    mbedtls_ssl_config       ssl_conf;
    mbedtls_x509_crt         ca_cert;
    mbedtls_x509_crt         client_cert;
    mbedtls_pk_context       private_key;
}qtf_tls_handle_t;

#if defined(MBEDTLS_DEBUG_C)
static void _ssl_debug(void *ctx, int level, const char *file, int line, const char *str)
{
    printf("[mbedTLS]:[%s]:[%d]: %s\r\n", (file), line, (str));
}

#endif

static int _mbedtls_tcp_connect(mbedtls_net_context *ctx, const char *host, uint16_t port)
{
    int ret = 0;
    char port_str[6] = {0};

snprintf(port_str, sizeof(port_str), "%d", port);

ret = mbedtls_net_connect(ctx, host, port_str, MBEDTLS_NET_PROTO_TCP);
    if(ret != 0)
    {
        dlg_error("mbedtls_net_connect connect failed returned 0x%04x errno: %d", ret < 0 ? -ret : ret, errno);

        return ret;
    }

ret = mbedtls_net_set_block(ctx);
    if(ret != 0)
    {
        dlg_error("mbedtls_net_set_block failed returned 0x%04x errno: %d", ret < 0 ? -ret : ret, errno);
        return ret;
    }

return 0;
}

static int _tls_net_init(qtf_tls_handle_t *handle, qtf_tls_conn_param_t *param)
{
    int ret = -1;

mbedtls_net_init(&(handle->socket_fd));
    mbedtls_ssl_init(&(handle->ssl));
    mbedtls_ssl_config_init(&(handle->ssl_conf));
    mbedtls_ctr_drbg_init(&(handle->ctr_drbg));

    mbedtls_entropy_init(&(handle->entropy));

#if defined(MBEDTLS_DEBUG_C)
    mbedtls_debug_set_threshold(param->debug_level);
    mbedtls_ssl_conf_dbg(&handle->ssl_conf, _ssl_debug, NULL);
#endif

#if defined(MBEDTLS_USE_PSA_CRYPTO) || defined(MBEDTLS_SSL_PROTO_TLS1_3)
    // tls 1.3 需要调用 psa_crypto_init
    ret = psa_crypto_init();
    if (ret != PSA_SUCCESS)
    {
        dlg_error("psa_crypto_init failed");
        goto error;
    }
#endif

ret = mbedtls_ssl_conf_max_frag_len(&(handle->ssl_conf), param->max_frag_len);
    if (ret != 0)
    {
        dlg_error("mbedtls_ssl_conf_max_frag_len failed");
        goto error;
    }

ret = mbedtls_ctr_drbg_seed(&(handle->ctr_drbg), mbedtls_entropy_func, &(handle->entropy), NULL, 0);
    if (ret != 0)
    {
        dlg_error("mbedtls_ctr_drbg_seed failed");
        goto error;
    }

    // 证书认证方式
    if(param->auth_mode == QTF_TLS_AUTH_MODE_CERT)
    {
        if(param->ca_cert && param->ca_cert_len)
        {
            mbedtls_x509_crt_init(&(handle->ca_cert));
            ret = mbedtls_x509_crt_parse(&(handle->ca_cert), (const unsigned char *)param->ca_cert, param->ca_cert_len+1);
            if (ret != 0)
            {
                dlg_error("mbedtls_x509_crt_parse failed");
                goto error;
            }
        }
        else
        {
            if(param->verify_mode != QTF_TLS_VERIFY_MODE_NONE)
            {
                dlg_error("invalid ca cert");
                goto error;
            }
            dlg_info("verify mode is none");
        }

        mbedtls_ssl_conf_ca_chain(&(handle->ssl_conf), &(handle->ca_cert), NULL);

        if (param->client_cert && param->client_cert_len && param->client_key && param->client_key_len)
        {
            // 双向认证
            mbedtls_x509_crt_init(&(handle->client_cert));
            mbedtls_pk_init(&(handle->private_key));
            ret = mbedtls_x509_crt_parse(&(handle->client_cert), (const unsigned char *)param->client_cert, param->client_cert_len + 1);
            if (ret != 0)
            {
                dlg_error("mbedtls_x509_crt_parse failed");
                goto error;
            }

ret = mbedtls_pk_parse_key(&(handle->private_key), (const unsigned char *)param->client_key,
                                       param->client_key_len + 1, (const unsigned char *)param->client_key_passwd, param->client_key_passwd_len + 1, NULL, NULL);
            if (ret != 0)
            {
                dlg_error("mbedtls_pk_parse_key failed");
                goto error;
            }
            ret = mbedtls_ssl_conf_own_cert(&(handle->ssl_conf), &(handle->client_cert), &(handle->private_key));
            if (ret != 0)
            {
                dlg_error("mbedtls_ssl_conf_own_cert failed");
                goto error;
            }
        }
    }
    // psk 认证
    else if(param->auth_mode == QTF_TLS_AUTH_MODE_PSK)
    {
        if(param->psk && param->psk_len && param->psk_id)
        {
            ret = mbedtls_ssl_conf_psk(&(handle->ssl_conf), (const unsigned char *)param->psk, param->psk_len,
                                       (const unsigned char *)param->psk_id, strlen(param->psk_id));
            if (ret != 0)
            {
                dlg_error("mbedtls_ssl_conf_psk failed");
                goto error;
            }
        }
        else
        {
            dlg_error("invalid psk");
            goto error;
        }
    }
    else
    {
        dlg_error("invalid auth mode");
        goto error;
    }
    return ret;

error:

    return ret;

}

static int __tls_net_deinit(qtf_tls_handle_t *handle)
{
    mbedtls_net_free(&(handle->socket_fd));
    mbedtls_ssl_free(&(handle->ssl));
    mbedtls_ssl_config_free(&(handle->ssl_conf));
    mbedtls_ctr_drbg_free(&(handle->ctr_drbg));
    mbedtls_entropy_free(&(handle->entropy));
    mbedtls_x509_crt_free(&(handle->ca_cert));
    mbedtls_x509_crt_free(&(handle->client_cert));
    mbedtls_pk_free(&(handle->private_key));

return 0;
}

void *qtf_tls_connect(const char *host, uint16_t port, qtf_tls_conn_param_t *param)
{
    qtf_tls_handle_t *handle = NULL;
    int ret = 0;

if(!host || !param)
    {
        dlg_error("invalid param");
        goto error;
    }

handle = (qtf_tls_handle_t *)malloc(sizeof(qtf_tls_handle_t));
    if(!handle)
    {
        dlg_error("malloc failed");
        goto error;
    }

    // 配置 tls 连接参数
    ret = _tls_net_init(handle, param);
    if(ret != 0)
    {
        dlg_error("tls net init failed");
        goto error;
    }

dlg_info("Connecting to %s:%d...", host, port);
	// 建立 tcp 连接
    ret = _mbedtls_tcp_connect(&(handle->socket_fd), host, port);
    if (ret != 0)
    {
        dlg_error("mbedtls_tcp_connect failed");
        goto error;
    }

    // 设置 tls 客户端
    mbedtls_ssl_config_defaults(&(handle->ssl_conf), MBEDTLS_SSL_IS_CLIENT, MBEDTLS_SSL_TRANSPORT_STREAM, MBEDTLS_SSL_PRESET_DEFAULT);

mbedtls_ssl_conf_read_timeout(&(handle->ssl_conf), param->hanshake_timeout_ms);

    // 配置认证等级
    mbedtls_ssl_conf_authmode(&(handle->ssl_conf), param->verify_mode);

    // 协议版本设置
    if(param->tls_version == QTF_TLS_VERSION_TLS1_2)
    {
        mbedtls_ssl_conf_max_tls_version(&(handle->ssl_conf), MBEDTLS_SSL_VERSION_TLS1_2);
        mbedtls_ssl_conf_min_tls_version(&(handle->ssl_conf), MBEDTLS_SSL_VERSION_TLS1_2);
    }
    else if(param->tls_version == QTF_TLS_VERSION_TLS1_3)
    {
        mbedtls_ssl_conf_max_tls_version(&(handle->ssl_conf), MBEDTLS_SSL_VERSION_TLS1_3);
        mbedtls_ssl_conf_min_tls_version(&(handle->ssl_conf), MBEDTLS_SSL_VERSION_TLS1_3);
    }
    else
    {
        mbedtls_ssl_conf_max_tls_version(&(handle->ssl_conf), MBEDTLS_SSL_VERSION_TLS1_3);
        mbedtls_ssl_conf_min_tls_version(&(handle->ssl_conf), MBEDTLS_SSL_VERSION_TLS1_2);
    }

mbedtls_ssl_conf_rng(&(handle->ssl_conf), mbedtls_ctr_drbg_random, &(handle->ctr_drbg));

// todo: config ciphersuites

ret = mbedtls_ssl_setup(&(handle->ssl), &(handle->ssl_conf));
    if (ret != 0)
    {
        dlg_error("mbedtls_ssl_setup failed");
        goto error;
    }

    // 配置 tcp 收发函数，可自定义也可使用 mbedtls 的实现
    mbedtls_ssl_set_bio(&(handle->ssl), &(handle->socket_fd), mbedtls_net_send, mbedtls_net_recv, mbedtls_net_recv_timeout);

    // 设置服务器域名，目的是配置 SNI （Server Name Indication） 扩展。
    ret = mbedtls_ssl_set_hostname(&(handle->ssl), host);
    if (ret != 0)
    {
        dlg_error("mbedtls_ssl_set_hostname failed");
        goto error;
    }

// 执行握手流程
    while ((ret = mbedtls_ssl_handshake(&(handle->ssl))) != 0)
    {
        if (ret != MBEDTLS_ERR_SSL_WANT_READ && ret != MBEDTLS_ERR_SSL_WANT_WRITE)
        {
            dlg_error("mbedtls_ssl_handshake failed 0x%04x", ret < 0 ? -ret : ret);
            goto error;
        }
    }

    // 证书校验结果
    ret = mbedtls_ssl_get_verify_result(&(handle->ssl));
    if (ret < 0)
    {
        dlg_error("mbedtls_ssl_get_verify_result  0x%04x", ret < 0 ? -ret : ret);
        goto error;
    }

return handle;

error:

if(handle)
    {
        __tls_net_deinit(handle);
        free(handle);
    }

return NULL;
}

int qtf_tls_send(void *handle, const void *buf, uint32_t len, uint32_t timeout_ms)
{
    qtf_tls_handle_t *tls_handle = (qtf_tls_handle_t *)handle;
    int ret = 0;

if(!handle || !buf || !len)
    {
        dlg_error("invalid param");
        return -1;
    }
	// 发送数据
    while ((ret = mbedtls_ssl_write(&(tls_handle->ssl), (const unsigned char *)buf, len)) <= 0)
    {
        if (ret != MBEDTLS_ERR_SSL_WANT_READ && ret != MBEDTLS_ERR_SSL_WANT_WRITE)
        {
            dlg_error("mbedtls_ssl_write failed 0x%04x", ret < 0 ? -ret : ret);
            return -1;
        }
    }

return ret;
}
int qtf_tls_recv(void *handle, void *buf, uint32_t len, uint32_t timeout_ms)
{
    qtf_tls_handle_t *tls_handle = (qtf_tls_handle_t *)handle;
    int ret = 0;

if(!handle || !buf || !len)
    {
        dlg_error("invalid param");
        return -1;
    }
	// 接收数据
    while ((ret = mbedtls_ssl_read(&(tls_handle->ssl), (unsigned char *)buf, len)) <= 0)
    {
        if (ret != MBEDTLS_ERR_SSL_WANT_READ && ret != MBEDTLS_ERR_SSL_WANT_WRITE)
        {
            dlg_error("mbedtls_ssl_read failed 0x%04x", ret < 0 ? -ret : ret);
            return -1;
        }
    }

return ret;
}

int qtf_tls_close(void *handle)
{
    int ret = 0;
    qtf_tls_handle_t *tls_handle = (qtf_tls_handle_t *)handle;

if (!handle)
    {
        dlg_error("invalid param");
        return -1;
    }
	// 关闭连接，释放资源
    do
    {
        ret = mbedtls_ssl_close_notify(&(tls_handle->ssl));
    } while (ret == MBEDTLS_ERR_SSL_WANT_READ || ret == MBEDTLS_ERR_SSL_WANT_WRITE);

__tls_net_deinit(tls_handle);
    free(tls_handle);

return 0;
}

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230

231

232

233

234

235

236

237

238

239

240

241

242

243

244

245

246

247

248

249

250

251

252

253

254

255

256

257

258

259

260

261

262

263

264

265

266

267

268

269

270

271

272

273

274

275

276

277

278

279

280

281

282

283

284

285

286

287

288

289

290

291

292

293

294

295

296

297

298

299

300

301

302

303

304

305

306

307

308

309

310

311

312

313

314

315

316

317

318

319

320

321

322

323

324

325

326

327

328

329

330

331

332

333

334

335

336

337

338

339

340

341

342

343

344

345

346

347

348

349

350

351

352

353

354

355

356

357

358

359

360

361

362

363

364

365

366

367

368

369

370

371

372

373

374

375

376

377

378

379

380

#include <stdio.h>

#include <stdlib.h>

#include <string.h>

#include "qt_idf_tls.h"

#include "dlg/dlg.h"

#include "mbedtls/net_sockets.h"

#include "mbedtls/ssl.h"

#include "mbedtls/ctr_drbg.h"

#include "mbedtls/debug.h"

#include "mbedtls/platform.h"

#include "mbedtls/timing.h"

#include "mbedtls/entropy.h"

#include "mbedtls/error.h"

typedef struct

{

mbedtls_net_context socket_fd;

mbedtls_entropy_context entropy;

mbedtls_ctr_drbg_context ctr_drbg;

mbedtls_ssl_context ssl;

mbedtls_ssl_config ssl_conf;

mbedtls_x509_crt ca_cert;

mbedtls_x509_crt client_cert;

mbedtls_pk_context private_key;

}qtf_tls_handle_t;

#if defined(MBEDTLS_DEBUG_C)

static void _ssl_debug(void *ctx, int level, const char *file, int line, const char *str)

{

printf("[mbedTLS]:[%s]:[%d]: %s\r\n", (file), line, (str));

}

#endif

static int _mbedtls_tcp_connect(mbedtls_net_context *ctx, const char *host, uint16_t port)

{

int ret = 0;

char port_str[6] = {0};

snprintf(port_str, sizeof(port_str), "%d", port);

ret = mbedtls_net_connect(ctx, host, port_str, MBEDTLS_NET_PROTO_TCP);

if(ret != 0)

{

dlg_error("mbedtls_net_connect connect failed returned 0x%04x errno: %d", ret < 0 ? -ret : ret, errno);

return ret;

}

ret = mbedtls_net_set_block(ctx);

if(ret != 0)

{

dlg_error("mbedtls_net_set_block failed returned 0x%04x errno: %d", ret < 0 ? -ret : ret, errno);

return ret;

}

return 0;

}

static int _tls_net_init(qtf_tls_handle_t *handle, qtf_tls_conn_param_t *param)

{

int ret = -1;

mbedtls_net_init(&(handle->socket_fd));

mbedtls_ssl_init(&(handle->ssl));

mbedtls_ssl_config_init(&(handle->ssl_conf));

mbedtls_ctr_drbg_init(&(handle->ctr_drbg));

mbedtls_entropy_init(&(handle->entropy));

#if defined(MBEDTLS_DEBUG_C)

mbedtls_debug_set_threshold(param->debug_level);

mbedtls_ssl_conf_dbg(&handle->ssl_conf, _ssl_debug, NULL);

#endif

#if defined(MBEDTLS_USE_PSA_CRYPTO) || defined(MBEDTLS_SSL_PROTO_TLS1_3)

// tls 1.3 需要调用 psa_crypto_init

ret = psa_crypto_init();

if (ret != PSA_SUCCESS)

{

dlg_error("psa_crypto_init failed");

goto error;

}

#endif

ret = mbedtls_ssl_conf_max_frag_len(&(handle->ssl_conf), param->max_frag_len);

if (ret != 0)

{

dlg_error("mbedtls_ssl_conf_max_frag_len failed");

goto error;

}

ret = mbedtls_ctr_drbg_seed(&(handle->ctr_drbg), mbedtls_entropy_func, &(handle->entropy), NULL, 0);

if (ret != 0)

{

dlg_error("mbedtls_ctr_drbg_seed failed");

goto error;

}

// 证书认证方式

if(param->auth_mode == QTF_TLS_AUTH_MODE_CERT)

{

if(param->ca_cert && param->ca_cert_len)

{

mbedtls_x509_crt_init(&(handle->ca_cert));

ret = mbedtls_x509_crt_parse(&(handle->ca_cert), (const unsigned char *)param->ca_cert, param->ca_cert_len+1);

if (ret != 0)

{

dlg_error("mbedtls_x509_crt_parse failed");

goto error;

}

else

{

if(param->verify_mode != QTF_TLS_VERIFY_MODE_NONE)

{

dlg_error("invalid ca cert");

goto error;

}

dlg_info("verify mode is none");

}

mbedtls_ssl_conf_ca_chain(&(handle->ssl_conf), &(handle->ca_cert), NULL);

if (param->client_cert && param->client_cert_len && param->client_key && param->client_key_len)

{

// 双向认证

mbedtls_x509_crt_init(&(handle->client_cert));

mbedtls_pk_init(&(handle->private_key));

ret = mbedtls_x509_crt_parse(&(handle->client_cert), (const unsigned char *)param->client_cert, param->client_cert_len + 1);

if (ret != 0)

{

dlg_error("mbedtls_x509_crt_parse failed");

goto error;

}

ret = mbedtls_pk_parse_key(&(handle->private_key), (const unsigned char *)param->client_key,

param->client_key_len + 1, (const unsigned char *)param->client_key_passwd, param->client_key_passwd_len + 1, NULL, NULL);

if (ret != 0)

{

dlg_error("mbedtls_pk_parse_key failed");

goto error;

}

ret = mbedtls_ssl_conf_own_cert(&(handle->ssl_conf), &(handle->client_cert), &(handle->private_key));

if (ret != 0)

{

dlg_error("mbedtls_ssl_conf_own_cert failed");

goto error;

}

// psk 认证

else if(param->auth_mode == QTF_TLS_AUTH_MODE_PSK)

{

if(param->psk && param->psk_len && param->psk_id)

{

ret = mbedtls_ssl_conf_psk(&(handle->ssl_conf), (const unsigned char *)param->psk, param->psk_len,

(const unsigned char *)param->psk_id, strlen(param->psk_id));

if (ret != 0)

{

dlg_error("mbedtls_ssl_conf_psk failed");

goto error;

}

else

{

dlg_error("invalid psk");

goto error;

}

else

{

dlg_error("invalid auth mode");

goto error;

}

return ret;

error:

return ret;

}

static int __tls_net_deinit(qtf_tls_handle_t *handle)

{

mbedtls_net_free(&(handle->socket_fd));

mbedtls_ssl_free(&(handle->ssl));

mbedtls_ssl_config_free(&(handle->ssl_conf));

mbedtls_ctr_drbg_free(&(handle->ctr_drbg));

mbedtls_entropy_free(&(handle->entropy));

mbedtls_x509_crt_free(&(handle->ca_cert));

mbedtls_x509_crt_free(&(handle->client_cert));

mbedtls_pk_free(&(handle->private_key));

return 0;

}

void *qtf_tls_connect(const char *host, uint16_t port, qtf_tls_conn_param_t *param)

{

qtf_tls_handle_t *handle = NULL;

int ret = 0;

if(!host || !param)

{

dlg_error("invalid param");

goto error;

}

handle = (qtf_tls_handle_t *)malloc(sizeof(qtf_tls_handle_t));

if(!handle)

{

dlg_error("malloc failed");

goto error;

}

// 配置 tls 连接参数

ret = _tls_net_init(handle, param);

if(ret != 0)

{

dlg_error("tls net init failed");

goto error;

}

dlg_info("Connecting to %s:%d...", host, port);

// 建立 tcp 连接

ret = _mbedtls_tcp_connect(&(handle->socket_fd), host, port);

if (ret != 0)

{

dlg_error("mbedtls_tcp_connect failed");

goto error;

}

// 设置 tls 客户端

mbedtls_ssl_config_defaults(&(handle->ssl_conf), MBEDTLS_SSL_IS_CLIENT, MBEDTLS_SSL_TRANSPORT_STREAM, MBEDTLS_SSL_PRESET_DEFAULT);

mbedtls_ssl_conf_read_timeout(&(handle->ssl_conf), param->hanshake_timeout_ms);

// 配置认证等级

mbedtls_ssl_conf_authmode(&(handle->ssl_conf), param->verify_mode);

// 协议版本设置

if(param->tls_version == QTF_TLS_VERSION_TLS1_2)

{

mbedtls_ssl_conf_max_tls_version(&(handle->ssl_conf), MBEDTLS_SSL_VERSION_TLS1_2);

mbedtls_ssl_conf_min_tls_version(&(handle->ssl_conf), MBEDTLS_SSL_VERSION_TLS1_2);

}

else if(param->tls_version == QTF_TLS_VERSION_TLS1_3)

{

mbedtls_ssl_conf_max_tls_version(&(handle->ssl_conf), MBEDTLS_SSL_VERSION_TLS1_3);

mbedtls_ssl_conf_min_tls_version(&(handle->ssl_conf), MBEDTLS_SSL_VERSION_TLS1_3);

}

else

{

mbedtls_ssl_conf_max_tls_version(&(handle->ssl_conf), MBEDTLS_SSL_VERSION_TLS1_3);

mbedtls_ssl_conf_min_tls_version(&(handle->ssl_conf), MBEDTLS_SSL_VERSION_TLS1_2);

}

mbedtls_ssl_conf_rng(&(handle->ssl_conf), mbedtls_ctr_drbg_random, &(handle->ctr_drbg));

// todo: config ciphersuites

ret = mbedtls_ssl_setup(&(handle->ssl), &(handle->ssl_conf));

if (ret != 0)

{

dlg_error("mbedtls_ssl_setup failed");

goto error;

}

// 配置 tcp 收发函数，可自定义也可使用 mbedtls 的实现

mbedtls_ssl_set_bio(&(handle->ssl), &(handle->socket_fd), mbedtls_net_send, mbedtls_net_recv, mbedtls_net_recv_timeout);

// 设置服务器域名，目的是配置 SNI （Server Name Indication）扩展。

ret = mbedtls_ssl_set_hostname(&(handle->ssl), host);

if (ret != 0)

{

dlg_error("mbedtls_ssl_set_hostname failed");

goto error;

}

// 执行握手流程

while ((ret = mbedtls_ssl_handshake(&(handle->ssl))) != 0)

{

if (ret != MBEDTLS_ERR_SSL_WANT_READ && ret != MBEDTLS_ERR_SSL_WANT_WRITE)

{

dlg_error("mbedtls_ssl_handshake failed 0x%04x", ret < 0 ? -ret : ret);

goto error;

}

// 证书校验结果

ret = mbedtls_ssl_get_verify_result(&(handle->ssl));

if (ret < 0)

{

dlg_error("mbedtls_ssl_get_verify_result 0x%04x", ret < 0 ? -ret : ret);

goto error;

}

return handle;

error:

if(handle)

{

__tls_net_deinit(handle);

free(handle);

}

return NULL;

}

int qtf_tls_send(void *handle, const void *buf, uint32_t len, uint32_t timeout_ms)

{

qtf_tls_handle_t *tls_handle = (qtf_tls_handle_t *)handle;

int ret = 0;

if(!handle || !buf || !len)

{

dlg_error("invalid param");

return -1;

}

// 发送数据

while ((ret = mbedtls_ssl_write(&(tls_handle->ssl), (const unsigned char *)buf, len)) <= 0)

{

if (ret != MBEDTLS_ERR_SSL_WANT_READ && ret != MBEDTLS_ERR_SSL_WANT_WRITE)

{

dlg_error("mbedtls_ssl_write failed 0x%04x", ret < 0 ? -ret : ret);

return -1;

}

return ret;

}

int qtf_tls_recv(void *handle, void *buf, uint32_t len, uint32_t timeout_ms)

{

qtf_tls_handle_t *tls_handle = (qtf_tls_handle_t *)handle;

int ret = 0;

if(!handle || !buf || !len)

{

dlg_error("invalid param");

return -1;

}

// 接收数据

while ((ret = mbedtls_ssl_read(&(tls_handle->ssl), (unsigned char *)buf, len)) <= 0)

{

if (ret != MBEDTLS_ERR_SSL_WANT_READ && ret != MBEDTLS_ERR_SSL_WANT_WRITE)

{

dlg_error("mbedtls_ssl_read failed 0x%04x", ret < 0 ? -ret : ret);

return -1;

}

return ret;

}

int qtf_tls_close(void *handle)

{

int ret = 0;

qtf_tls_handle_t *tls_handle = (qtf_tls_handle_t *)handle;

if (!handle)

{

dlg_error("invalid param");

return -1;

}

// 关闭连接，释放资源

{

ret = mbedtls_ssl_close_notify(&(tls_handle->ssl));

} while (ret == MBEDTLS_ERR_SSL_WANT_READ || ret == MBEDTLS_ERR_SSL_WANT_WRITE);

__tls_net_deinit(tls_handle);

free(tls_handle);

return 0;

}

测试例子

测试代码，连接 https 测试服务器 httpbin.org，发送一个 get 请求，并接收服务器回复。

void shell_tlstest_cmd(int argc, char *argv)
{
	qtf_tls_conn_param_t tls_param = {0};
	void *tls_handle = NULL;
	char recv_buf[1024] = {0};
	int ret = 0;

const char request[] = "GET /get?a=1 HTTP/1.1\r\n"
		"Host: httpbin.org\r\n"
		"Connection: close\r\n"
		"\r\n";
	const char *test_ca_cert =
		{

"-----BEGIN CERTIFICATE-----\r\n"
			"MIIDdTCCAl2gAwIBAgILBAAAAAABFUtaw5QwDQYJKoZIhvcNAQEFBQAwVzELMAkG\r\n"
			"A1UEBhMCQkUxGTAXBgNVBAoTEEdsb2JhbFNpZ24gbnYtc2ExEDAOBgNVBAsTB1Jv\r\n"
			"b3QgQ0ExGzAZBgNVBAMTEkdsb2JhbFNpZ24gUm9vdCBDQTAeFw05ODA5MDExMjAw\r\n"
			"MDBaFw0yODAxMjgxMjAwMDBaMFcxCzAJBgNVBAYTAkJFMRkwFwYDVQQKExBHbG9i\r\n"
			"YWxTaWduIG52LXNhMRAwDgYDVQQLEwdSb290IENBMRswGQYDVQQDExJHbG9iYWxT\r\n"
			"aWduIFJvb3QgQ0EwggEiMA0GCSqGSIb3DQEBAQUAA4IBDwAwggEKAoIBAQDaDuaZ\r\n"
			"jc6j40+Kfvvxi4Mla+pIH/EqsLmVEQS98GPR4mdmzxzdzxtIK+6NiY6arymAZavp\r\n"
			"xy0Sy6scTHAHoT0KMM0VjU/43dSMUBUc71DuxC73/OlS8pF94G3VNTCOXkNz8kHp\r\n"
			"1Wrjsok6Vjk4bwY8iGlbKk3Fp1S4bInMm/k8yuX9ifUSPJJ4ltbcdG6TRGHRjcdG\r\n"
			"snUOhugZitVtbNV4FpWi6cgKOOvyJBNPc1STE4U6G7weNLWLBYy5d4ux2x8gkasJ\r\n"
			"U26Qzns3dLlwR5EiUWMWea6xrkEmCMgZK9FGqkjWZCrXgzT/LCrBbBlDSgeF59N8\r\n"
			"9iFo7+ryUp9/k5DPAgMBAAGjQjBAMA4GA1UdDwEB/wQEAwIBBjAPBgNVHRMBAf8E\r\n"
			"BTADAQH/MB0GA1UdDgQWBBRge2YaRQ2XyolQL30EzTSo//z9SzANBgkqhkiG9w0B\r\n"
			"AQUFAAOCAQEA1nPnfE920I2/7LqivjTFKDK1fPxsnCwrvQmeU79rXqoRSLblCKOz\r\n"
			"yj1hTdNGCbM+w6DjY1Ub8rrvrTnhQ7k4o+YviiY776BQVvnGCv04zcQLcFGUl5gE\r\n"
			"38NflNUVyRRBnMRddWQVDf9VMOyGj/8N7yy5Y0b2qvzfvGn9LhJIZJrglfCm7ymP\r\n"
			"AbEVtQwdpf5pLGkkeB6zpxxxYu7KyJesF12KwvhHhm4qxFYxldBniYUr+WymXUad\r\n"
			"DKqC5JlR3XC321Y9YeRq4VzW9v493kHMB65jUr9TU/Qr6cf9tveCX4XSQRjbgbME\r\n"
			"HMUfpIBvFSDJ3gyICh3WZlXi/EjJKSZp4A==\r\n"
			"-----END CERTIFICATE-----"};
	tls_param.auth_mode = QTF_TLS_AUTH_MODE_CERT;
	tls_param.verify_mode = QTF_TLS_VERIFY_MODE_OPTIONAL;
	tls_param.hanshake_timeout_ms = 10000;
	tls_param.ca_cert = test_ca_cert;
	tls_param.ca_cert_len = strlen(test_ca_cert);
	tls_param.client_cert = NULL;
	tls_param.client_cert_len = 0;
	tls_param.client_key = NULL;
	tls_param.client_key_len = 0;
	tls_param.client_key_passwd = NULL;
	tls_param.client_key_passwd_len = 0;
	tls_param.psk = NULL;
	tls_param.psk_len = 0;
	tls_param.psk_id = NULL;
	tls_param.debug_level = QTF_TLS_DEBUG_LEVEL_ERROR;
	tls_param.tls_version = QTF_TLS_VERSION_TLS1_2;
	tls_param.max_frag_len = QTF_TLS_MAX_FRAG_LEN_NO_USE;

tls_handle = qtf_tls_connect("httpbin.org", 443, &tls_param);
	if(tls_handle)
	{
		shell_printf("tls connect success\r\n");
	}
	else
	{
		shell_printf("tls connect failed\r\n");
		return;
	}

ret = qtf_tls_send(tls_handle, request, strlen(request), 1000);
	if(ret > 0)
	{
		shell_printf("tls send success\r\n");
	}
	else
	{
		shell_printf("tls send failed\r\n");
		qtf_tls_close(tls_handle);
		return;
	}

ret = qtf_tls_recv(tls_handle, recv_buf, sizeof(recv_buf), 1000);
	if(ret > 0)
	{
		shell_printf("tls recv success\r\n");
		shell_printf("recv:%s\r\n", recv_buf);
	}
	else
	{
		shell_printf("tls recv failed\r\n");
	}

qtf_tls_close(tls_handle);

}

void shell_tlstest_cmd(int argc, char *argv)

{

qtf_tls_conn_param_t tls_param = {0};

void *tls_handle = NULL;

char recv_buf[1024] = {0};

int ret = 0;

const char request[] = "GET /get?a=1 HTTP/1.1\r\n"

"Host: httpbin.org\r\n"

"Connection: close\r\n"

"\r\n";

const char *test_ca_cert =

{

"-----BEGIN CERTIFICATE-----\r\n"

"MIIDdTCCAl2gAwIBAgILBAAAAAABFUtaw5QwDQYJKoZIhvcNAQEFBQAwVzELMAkG\r\n"

"A1UEBhMCQkUxGTAXBgNVBAoTEEdsb2JhbFNpZ24gbnYtc2ExEDAOBgNVBAsTB1Jv\r\n"

"b3QgQ0ExGzAZBgNVBAMTEkdsb2JhbFNpZ24gUm9vdCBDQTAeFw05ODA5MDExMjAw\r\n"

"MDBaFw0yODAxMjgxMjAwMDBaMFcxCzAJBgNVBAYTAkJFMRkwFwYDVQQKExBHbG9i\r\n"

"YWxTaWduIG52LXNhMRAwDgYDVQQLEwdSb290IENBMRswGQYDVQQDExJHbG9iYWxT\r\n"

"aWduIFJvb3QgQ0EwggEiMA0GCSqGSIb3DQEBAQUAA4IBDwAwggEKAoIBAQDaDuaZ\r\n"

"jc6j40+Kfvvxi4Mla+pIH/EqsLmVEQS98GPR4mdmzxzdzxtIK+6NiY6arymAZavp\r\n"

"xy0Sy6scTHAHoT0KMM0VjU/43dSMUBUc71DuxC73/OlS8pF94G3VNTCOXkNz8kHp\r\n"

"1Wrjsok6Vjk4bwY8iGlbKk3Fp1S4bInMm/k8yuX9ifUSPJJ4ltbcdG6TRGHRjcdG\r\n"

"snUOhugZitVtbNV4FpWi6cgKOOvyJBNPc1STE4U6G7weNLWLBYy5d4ux2x8gkasJ\r\n"

"U26Qzns3dLlwR5EiUWMWea6xrkEmCMgZK9FGqkjWZCrXgzT/LCrBbBlDSgeF59N8\r\n"

"9iFo7+ryUp9/k5DPAgMBAAGjQjBAMA4GA1UdDwEB/wQEAwIBBjAPBgNVHRMBAf8E\r\n"

"BTADAQH/MB0GA1UdDgQWBBRge2YaRQ2XyolQL30EzTSo//z9SzANBgkqhkiG9w0B\r\n"

"AQUFAAOCAQEA1nPnfE920I2/7LqivjTFKDK1fPxsnCwrvQmeU79rXqoRSLblCKOz\r\n"

"yj1hTdNGCbM+w6DjY1Ub8rrvrTnhQ7k4o+YviiY776BQVvnGCv04zcQLcFGUl5gE\r\n"

"38NflNUVyRRBnMRddWQVDf9VMOyGj/8N7yy5Y0b2qvzfvGn9LhJIZJrglfCm7ymP\r\n"

"AbEVtQwdpf5pLGkkeB6zpxxxYu7KyJesF12KwvhHhm4qxFYxldBniYUr+WymXUad\r\n"

"DKqC5JlR3XC321Y9YeRq4VzW9v493kHMB65jUr9TU/Qr6cf9tveCX4XSQRjbgbME\r\n"

"HMUfpIBvFSDJ3gyICh3WZlXi/EjJKSZp4A==\r\n"

"-----END CERTIFICATE-----"};

tls_param.auth_mode = QTF_TLS_AUTH_MODE_CERT;

tls_param.verify_mode = QTF_TLS_VERIFY_MODE_OPTIONAL;

tls_param.hanshake_timeout_ms = 10000;

tls_param.ca_cert = test_ca_cert;

tls_param.ca_cert_len = strlen(test_ca_cert);

tls_param.client_cert = NULL;

tls_param.client_cert_len = 0;

tls_param.client_key = NULL;

tls_param.client_key_len = 0;

tls_param.client_key_passwd = NULL;

tls_param.client_key_passwd_len = 0;

tls_param.psk = NULL;

tls_param.psk_len = 0;

tls_param.psk_id = NULL;

tls_param.debug_level = QTF_TLS_DEBUG_LEVEL_ERROR;

tls_param.tls_version = QTF_TLS_VERSION_TLS1_2;

tls_param.max_frag_len = QTF_TLS_MAX_FRAG_LEN_NO_USE;

tls_handle = qtf_tls_connect("httpbin.org", 443, &tls_param);

if(tls_handle)

{

shell_printf("tls connect success\r\n");

}

else

{

shell_printf("tls connect failed\r\n");

return;

}

ret = qtf_tls_send(tls_handle, request, strlen(request), 1000);

if(ret > 0)

{

shell_printf("tls send success\r\n");

}

else

{

shell_printf("tls send failed\r\n");

qtf_tls_close(tls_handle);

return;

}

ret = qtf_tls_recv(tls_handle, recv_buf, sizeof(recv_buf), 1000);

if(ret > 0)

{

shell_printf("tls recv success\r\n");

shell_printf("recv:%s\r\n", recv_buf);

}

else

{

shell_printf("tls recv failed\r\n");

}

qtf_tls_close(tls_handle);

}

测试日志：

[qt_idf_tls.c:250 qtf_tls_connect] Connecting to httpbin.org:443...
[mbedTLS]:[D:/workspace/QT/qt_idf/components/mbedtls/library/ssl_client.c]:[258]: got supported group(001d)

[mbedTLS]:[D:/workspace/QT/qt_idf/components/mbedtls/library/ssl_client.c]:[258]: got supported group(0017)

[mbedTLS]:[D:/workspace/QT/qt_idf/components/mbedtls/library/ssl_client.c]:[258]: got supported group(0018)

[mbedTLS]:[D:/workspace/QT/qt_idf/components/mbedtls/library/ssl_client.c]:[258]: got supported group(001e)

[mbedTLS]:[D:/workspace/QT/qt_idf/components/mbedtls/library/ssl_client.c]:[258]: got supported group(0019)

[mbedTLS]:[D:/workspace/QT/qt_idf/components/mbedtls/library/ssl_client.c]:[258]: got supported group(001a)

[mbedTLS]:[D:/workspace/QT/qt_idf/components/mbedtls/library/ssl_client.c]:[258]: got supported group(001b)

[mbedTLS]:[D:/workspace/QT/qt_idf/components/mbedtls/library/ssl_client.c]:[258]: got supported group(001c)

[mbedTLS]:[D:/workspace/QT/qt_idf/components/mbedtls/library/ssl_tls.c]:[7384]: x509_verify_cert() returned -9984 (-0x2700)

[mbedTLS]:[D:/workspace/QT/qt_idf/components/mbedtls/library/ssl_tls12_client.c]:[2762]: Perform PSA-based ECDH computation.

tls connect success
tls send success
tls recv success
recv:HTTP/1.1 200 OK
Date: Sun, 02 Jul 2023 12:02:04 GMT
Content-Type: application/json
Content-Length: 220
Connection: close
Server: gunicorn/19.9.0
Access-Control-Allow-Origin: *
Access-Control-Allow-Credentials: true

{
  "args": {
    "a": "1"
  },
  "headers": {
    "Host": "httpbin.org",
    "X-Amzn-Trace-Id": "Root=1-64a1673a-5197ca4a2ff801443ac81bc6"
  },
  "origin": "223.73.211.183",
  "url": "https://httpbin.org/get?a=1"
}

[qt_idf_tls.c:250 qtf_tls_connect] Connecting to httpbin.org:443...

[mbedTLS]:[D:/workspace/QT/qt_idf/components/mbedtls/library/ssl_client.c]:[258]: got supported group(001d)
