前置条件

Ubuntu 24.04.2 LTS

内容详情

在使用Gtk开发应用程序的过程中，如果需要内嵌网页，那么使用libwebkit2gtk是个非常自然和正确的选择。

那么这里就可能原生程序代码可能需要跟网页交互的问题。

Gtk程序跟网页的交互，主要有两个方面：

1 Gtk程序需要调用网页js代码

2 网页需要调用 Gtk 程序的功能代码

1 Gtk程序需要调用网页js代码

2 网页需要调用 Gtk 程序的功能代码

需求1，使用 webkit2gtk 的内置 webkit_web_view_run_javascript 函数即可解决

需求2，使用 webkit2gtk 的内置的 web extendsion 扩展支持功能解决或 window.webkit.messageHandlers..postMessage(value)

不多说看代码吧！

Gtk嵌入网页Demo程序

webviewgtk.c

/**
 *
 * Copyright (C) 2020 Wei Keting<weikting@gmail.com>. All rights reserved.
 * @Time : 2021-04-04 12:18
 * @Last Modified: 2022-12-10 17:27
 * @File : webviewgtk.c
 * @Description :
 *
 * 依赖下载：
 * sudo apt install libwebkit2gtk-4.1-doc libwebkit2gtk-4.1-dev libgtk-3-dev
 * gcc webviewgtk.c -o webviewgtk -D_GNU_SOURCE -g3 -Wall `pkg-config --cflags --libs webkit2gtk-4.1`
 *
 */

#include <gtk/gtk.h>
#include <glib.h>
#include <webkit2/webkit2.h>

#include <sys/types.h>
#include <unistd.h>

static void
web_view_javascript_finished(GObject *object,
                             GAsyncResult *result,
                             gpointer user_data) {
    GError *error = NULL;

    JSCValue *js_result = webkit_web_view_evaluate_javascript_finish(WEBKIT_WEB_VIEW(object),
                                                                     result, &error);
    if (!js_result) {
        g_warning("Error running javascript: %s", error->message);
        g_error_free(error);
        return;
    }

    if (jsc_value_is_string(js_result)) {
        gchar *str_value = jsc_value_to_string(js_result);
        JSCException *exception = jsc_context_get_exception(jsc_value_get_context(js_result));
        if (exception)
            g_warning("Error running javascript: %s", jsc_exception_get_message(exception));
        else
            g_print("Script result: %s\n", str_value);
        g_free(str_value);
    } else {
        g_warning("Error running javascript: unexpected return value");
    }
}

static gboolean
on_webview_load_failed(WebKitWebView *webview,
                       WebKitLoadEvent load_event,
                       gchar *failing_uri,
                       GError *error,
                       gpointer user_data) {

    g_printerr("%s: %s\n", failing_uri, error->message);
    return FALSE;
}

static void
handle_script_message(WebKitUserContentManager *self,
                      WebKitJavascriptResult *js_result,
                      gpointer user_data) {

    JSCValue *value = webkit_javascript_result_get_js_value(js_result);

    gchar *str_value = jsc_value_to_string(value);
    JSCException *exception = jsc_context_get_exception(jsc_value_get_context(value));
    if (exception)
        g_warning("Error running javascript: %s", jsc_exception_get_message(exception));
    else
        g_printerr("Script result: %s\n", str_value);

    g_printerr("%s: %s\n", __func__, str_value);

    g_free(str_value);
}

static gboolean
handle_script_message_with_reply(WebKitUserContentManager *self,
                                 JSCValue *value,
                                 WebKitScriptMessageReply *reply,
                                 gpointer user_data) {

    gchar *str_value = jsc_value_to_string(value);
    JSCContext *context = jsc_value_get_context(value);
    /* It is possible to handle the reply asynchronously,
     * by simply calling g_object_ref() on the reply and returning TRUE.
     * webkit_script_message_reply_ref(reply);
     *
     * async code here
     *
     * webkit_script_message_reply_unref(reply);
     */

    JSCValue *js_value = jsc_value_new_string(context, str_value);
    webkit_script_message_reply_return_value(reply, js_value);

    g_printerr("%s: %s\n", __func__, str_value);

    g_free(str_value);

    return TRUE; // TRUE to stop other handlers from being invoked for the event. FALSE to propagate the event further.
}

static void
on_button_clicked(GtkButton *button,
                  WebKitWebView *webview) {
    static gint t = 0;
    gchar buf[128] = {0};
    g_snprintf(buf, sizeof(buf) - 1, "change_span_id('_n%d')", t);
    t += 1;
    // 在webview当前的html页面中直接运行js代码
    webkit_web_view_evaluate_javascript(webview, buf, -1, NULL, NULL, NULL,
                                        web_view_javascript_finished, NULL);
}

static void
webkit_web_extension_initialize(WebKitWebContext *context,
                                gpointer user_data) {

    g_printerr("%s: %d\n", __FUNCTION__, getpid());
    // 设置web extendsion扩张.so文件的搜索目录
    webkit_web_context_set_web_extensions_directory(context, ".");
}

/**
** 创建window，添加webkit控件
**
**/
static void
on_activate(GtkApplication *app) {

    g_assert(GTK_IS_APPLICATION(app));

    GtkWindow *window = gtk_application_get_active_window(app);
    if (window == NULL)
        window = g_object_new(GTK_TYPE_WINDOW,
                              "application", app,
                              "default-width", 600,
                              "default-height", 300,
                              NULL);

    // 注册处理web extensions的初始化函数
    g_signal_connect(webkit_web_context_get_default(), "initialize-web-extensions",
                     G_CALLBACK(webkit_web_extension_initialize), NULL);

    GtkWidget *webview = webkit_web_view_new();
    g_signal_connect(webview, "load-failed", G_CALLBACK(on_webview_load_failed), NULL);

    // 加载网页
    GFile *file = g_file_new_for_path("webview.html");
    gchar *uri = g_file_get_uri(file);
    webkit_web_view_load_uri(WEBKIT_WEB_VIEW(webview), uri);
    g_free(uri);
    g_object_unref(file);

    // 注册 window.webkit.messageHandlers.msgToNative.postMessage(value) 的回调函数
    WebKitUserContentManager *manager = webkit_web_view_get_user_content_manager(
            WEBKIT_WEB_VIEW(webview));
    g_signal_connect(manager, "script-message-received::msgToNative",
                     G_CALLBACK(handle_script_message), NULL);
    webkit_user_content_manager_register_script_message_handler(manager, "msgToNative");

    // 注册 window.webkit.messageHandlers.msgToNativeReply.postMessage(value) 的回调函数
    // 函数调用有返回值
    g_signal_connect(manager, "script-message-with-reply-received::msgToNativeReply",
                     G_CALLBACK(handle_script_message_with_reply), NULL);
    webkit_user_content_manager_register_script_message_handler_with_reply(manager,
                                                                           "msgToNativeReply",
                                                                           NULL);

    /* Enable the developer extras */
    WebKitSettings *setting = webkit_web_view_get_settings(WEBKIT_WEB_VIEW(webview));
    g_object_set(G_OBJECT(settings), "enable-developer-extras", TRUE, NULL);

    GtkWidget *vbox = gtk_box_new(GTK_ORIENTATION_VERTICAL, 0);
    GtkWidget *button = gtk_button_new_with_label("change span");
    gtk_box_pack_start(GTK_BOX(vbox), GTK_WIDGET(webview), TRUE, TRUE, 0);
    gtk_box_pack_start(GTK_BOX(vbox), GTK_WIDGET(button), FALSE, TRUE, 0);

    gtk_container_add(GTK_CONTAINER(window), GTK_WIDGET(vbox));
    gtk_widget_show_all(GTK_WIDGET(vbox));
    gtk_window_present(window);

    g_signal_connect(button, "clicked", G_CALLBACK(on_button_clicked), webview);
}

int main(int argc,
         char *argv[]) {

    g_autoptr(GtkApplication)
    app = gtk_application_new("com.weiketing.webkit_webview", G_APPLICATION_DEFAULT_FLAGS);

    g_signal_connect(app, "activate", G_CALLBACK(on_activate), NULL);

    return g_application_run(G_APPLICATION(app), argc, argv);
}

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

/**

* @Time : 2021-04-04 12:18

* @Last Modified: 2022-12-10 17:27

* @File : webviewgtk.c

* @Description :

* 依赖下载：

* sudo apt install libwebkit2gtk-4.1-doc libwebkit2gtk-4.1-dev libgtk-3-dev

* gcc webviewgtk.c -o webviewgtk -D_GNU_SOURCE -g3 -Wall `pkg-config --cflags --libs webkit2gtk-4.1`

#include <gtk/gtk.h>

#include <glib.h>

#include <webkit2/webkit2.h>

#include <sys/types.h>

#include <unistd.h>

static void

web_view_javascript_finished(GObject *object,

GAsyncResult *result,

gpointer user_data) {

GError *error = NULL;

JSCValue *js_result = webkit_web_view_evaluate_javascript_finish(WEBKIT_WEB_VIEW(object),

result, &error);

if (!js_result) {

g_warning("Error running javascript: %s", error->message);

g_error_free(error);

return;

}

if (jsc_value_is_string(js_result)) {

gchar *str_value = jsc_value_to_string(js_result);

JSCException *exception = jsc_context_get_exception(jsc_value_get_context(js_result));

if (exception)

g_warning("Error running javascript: %s", jsc_exception_get_message(exception));

else

g_print("Script result: %s\n", str_value);

g_free(str_value);

} else {

g_warning("Error running javascript: unexpected return value");

}

static gboolean

on_webview_load_failed(WebKitWebView *webview,

WebKitLoadEvent load_event,

gchar *failing_uri,

GError *error,

gpointer user_data) {

g_printerr("%s: %s\n", failing_uri, error->message);

return FALSE;

}

static void

handle_script_message(WebKitUserContentManager *self,

WebKitJavascriptResult *js_result,

gpointer user_data) {

JSCValue *value = webkit_javascript_result_get_js_value(js_result);

gchar *str_value = jsc_value_to_string(value);

JSCException *exception = jsc_context_get_exception(jsc_value_get_context(value));

if (exception)

g_warning("Error running javascript: %s", jsc_exception_get_message(exception));

else

g_printerr("Script result: %s\n", str_value);

g_printerr("%s: %s\n", __func__, str_value);

g_free(str_value);

}

static gboolean

handle_script_message_with_reply(WebKitUserContentManager *self,

JSCValue *value,

WebKitScriptMessageReply *reply,

gpointer user_data) {

gchar *str_value = jsc_value_to_string(value);

JSCContext *context = jsc_value_get_context(value);

/* It is possible to handle the reply asynchronously,

* by simply calling g_object_ref() on the reply and returning TRUE.

* webkit_script_message_reply_ref(reply);

* async code here

* webkit_script_message_reply_unref(reply);

JSCValue *js_value = jsc_value_new_string(context, str_value);

webkit_script_message_reply_return_value(reply, js_value);

g_printerr("%s: %s\n", __func__, str_value);

g_free(str_value);

return TRUE; // TRUE to stop other handlers from being invoked for the event. FALSE to propagate the event further.

}

static void

on_button_clicked(GtkButton *button,

WebKitWebView *webview) {

static gint t = 0;

gchar buf[128] = {0};

g_snprintf(buf, sizeof(buf) - 1, "change_span_id('_n%d')", t);

t += 1;

// 在webview当前的html页面中直接运行js代码

webkit_web_view_evaluate_javascript(webview, buf, -1, NULL, NULL, NULL,

web_view_javascript_finished, NULL);

}

static void

webkit_web_extension_initialize(WebKitWebContext *context,

gpointer user_data) {

g_printerr("%s: %d\n", __FUNCTION__, getpid());

// 设置web extendsion扩张.so文件的搜索目录

webkit_web_context_set_web_extensions_directory(context, ".");

}

/**

** 创建window，添加webkit控件

**/

static void

on_activate(GtkApplication *app) {

g_assert(GTK_IS_APPLICATION(app));

GtkWindow *window = gtk_application_get_active_window(app);

if (window == NULL)

window = g_object_new(GTK_TYPE_WINDOW,

"application", app,

"default-width", 600,

"default-height", 300,

NULL);

// 注册处理web extensions的初始化函数

g_signal_connect(webkit_web_context_get_default(), "initialize-web-extensions",

G_CALLBACK(webkit_web_extension_initialize), NULL);

GtkWidget *webview = webkit_web_view_new();

g_signal_connect(webview, "load-failed", G_CALLBACK(on_webview_load_failed), NULL);

// 加载网页

GFile *file = g_file_new_for_path("webview.html");

gchar *uri = g_file_get_uri(file);

webkit_web_view_load_uri(WEBKIT_WEB_VIEW(webview), uri);

g_free(uri);

g_object_unref(file);

// 注册 window.webkit.messageHandlers.msgToNative.postMessage(value) 的回调函数

WebKitUserContentManager *manager = webkit_web_view_get_user_content_manager(

WEBKIT_WEB_VIEW(webview));

g_signal_connect(manager, "script-message-received::msgToNative",

G_CALLBACK(handle_script_message), NULL);

webkit_user_content_manager_register_script_message_handler(manager, "msgToNative");

// 注册 window.webkit.messageHandlers.msgToNativeReply.postMessage(value) 的回调函数

// 函数调用有返回值

g_signal_connect(manager, "script-message-with-reply-received::msgToNativeReply",

G_CALLBACK(handle_script_message_with_reply), NULL);

webkit_user_content_manager_register_script_message_handler_with_reply(manager,

"msgToNativeReply",

NULL);

/* Enable the developer extras */

WebKitSettings *setting = webkit_web_view_get_settings(WEBKIT_WEB_VIEW(webview));

g_object_set(G_OBJECT(settings), "enable-developer-extras", TRUE, NULL);

GtkWidget *vbox = gtk_box_new(GTK_ORIENTATION_VERTICAL, 0);

GtkWidget *button = gtk_button_new_with_label("change span");

gtk_box_pack_start(GTK_BOX(vbox), GTK_WIDGET(webview), TRUE, TRUE, 0);

gtk_box_pack_start(GTK_BOX(vbox), GTK_WIDGET(button), FALSE, TRUE, 0);

gtk_container_add(GTK_CONTAINER(window), GTK_WIDGET(vbox));

gtk_widget_show_all(GTK_WIDGET(vbox));

gtk_window_present(window);

g_signal_connect(button, "clicked", G_CALLBACK(on_button_clicked), webview);

}

int main(int argc,

char *argv[]) {

g_autoptr(GtkApplication)

app = gtk_application_new("com.weiketing.webkit_webview", G_APPLICATION_DEFAULT_FLAGS);

g_signal_connect(app, "activate", G_CALLBACK(on_activate), NULL);

return g_application_run(G_APPLICATION(app), argc, argv);

}

Web Extension Demo

/**
*
* Copyright (C) 2020 Wei Keting<weikting@gmail.com>. All rights reserved.
* @Time : 2021-04-04 12:18
* @File : web_exten.c
* @Description :
*
* 依赖下载：
* sudo apt install libwebkit2gtk-4.1-doc libwebkit2gtk-4.1-dev libgtk-3-dev
* gcc  web_exten.c -o libweb_exten.so -shared -Wl,-soname,libweb_exten.so -D_GNU_SOURCE -g3 -Wall `pkg-config --cflags --libs webkit2gtk-4.1`
**/

#include <glib.h>
#include <webkit2/webkit-web-extension.h>
#include <sys/types.h>
#include <unistd.h>

static gint
js_app_add(gpointer *first, gint num) {
    static gint N = 0;
    g_printerr("%s: %p\n", __FUNCTION__, first);
    N += num;
    return N;
}

static void
window_object_cleared_callback(WebKitScriptWorld *world,
                               WebKitWebPage *web_page,
                               WebKitFrame *frame,
                               gpointer user_data) {
    JSCContext *jsContext;

    jsContext = webkit_frame_get_js_context_for_script_world(frame, world);

    //添加一个js全局变量gtkValue
    jsc_context_set_value(jsContext, "gtkValue",
                          jsc_value_new_string(jsContext, "__test_js_exten"));
    /* Use JSC API to add the JavaScript code you want */

    //注册一个名为NativeTest的js类
    JSCClass *app = jsc_context_register_class(jsContext, "NativeTest", NULL, NULL,
                                               NULL); // g_object_new(JSC_TYPE_CLASS, "name", "JSApp", "context", jsContext, NULL);


    //给JSCClass类添加add方法
    jsc_class_add_method(app, "add", G_CALLBACK(js_app_add), NULL, NULL, G_TYPE_INT, 1, G_TYPE_INT,
                         NULL);

    //创建一个obj，作为JSCClass类绑定实例，JSCClass方法回调的第一个参数就是obj
    GObject *obj = g_object_new(G_TYPE_OBJECT, NULL);
    jsc_context_set_value(jsContext, "GtkNative", jsc_value_new_object(jsContext, obj, app));
    g_printerr("%s: %d %p\n", __FUNCTION__, getpid(), obj);
    g_object_unref(obj);
}

G_MODULE_EXPORT void
webkit_web_extension_initialize(WebKitWebExtension *extension) {
    //web extension的初始化函数
    g_signal_connect(webkit_script_world_get_default(),
                     "window-object-cleared",
                     G_CALLBACK(window_object_cleared_callback),
                     NULL);
}

/**

* @Time : 2021-04-04 12:18

* @File : web_exten.c

* @Description :

* 依赖下载：

* sudo apt install libwebkit2gtk-4.1-doc libwebkit2gtk-4.1-dev libgtk-3-dev

* gcc web_exten.c -o libweb_exten.so -shared -Wl,-soname,libweb_exten.so -D_GNU_SOURCE -g3 -Wall `pkg-config --cflags --libs webkit2gtk-4.1`

**/

#include <glib.h>

#include <webkit2/webkit-web-extension.h>

#include <sys/types.h>

#include <unistd.h>

static gint

js_app_add(gpointer *first, gint num) {

static gint N = 0;

g_printerr("%s: %p\n", __FUNCTION__, first);

N += num;

return N;

}

static void

window_object_cleared_callback(WebKitScriptWorld *world,

WebKitWebPage *web_page,

WebKitFrame *frame,

gpointer user_data) {

JSCContext *jsContext;

jsContext = webkit_frame_get_js_context_for_script_world(frame, world);

//添加一个js全局变量gtkValue

jsc_context_set_value(jsContext, "gtkValue",

jsc_value_new_string(jsContext, "__test_js_exten"));

/* Use JSC API to add the JavaScript code you want */

//注册一个名为NativeTest的js类

JSCClass *app = jsc_context_register_class(jsContext, "NativeTest", NULL, NULL,

NULL); // g_object_new(JSC_TYPE_CLASS, "name", "JSApp", "context", jsContext, NULL);

//给JSCClass类添加add方法

jsc_class_add_method(app, "add", G_CALLBACK(js_app_add), NULL, NULL, G_TYPE_INT, 1, G_TYPE_INT,

NULL);

//创建一个obj，作为JSCClass类绑定实例，JSCClass方法回调的第一个参数就是obj

GObject *obj = g_object_new(G_TYPE_OBJECT, NULL);

jsc_context_set_value(jsContext, "GtkNative", jsc_value_new_object(jsContext, obj, app));

g_printerr("%s: %d %p\n", __FUNCTION__, getpid(), obj);

g_object_unref(obj);

}

G_MODULE_EXPORT void

webkit_web_extension_initialize(WebKitWebExtension *extension) {

//web extension的初始化函数

g_signal_connect(webkit_script_world_get_default(),

"window-object-cleared",

G_CALLBACK(window_object_cleared_callback),

NULL);

}

内嵌的网页示例 webview.html

<!DOCTYPE html>
<html lang="zh">
<!--filename: webview.html -->

<head>
    <meta charset="utf-8" />
    <meta http-equiv="Content-Language" content="zh-CN">
    <meta http-equiv="X-UA-Compatible" content="IE=edge,chrome=1" />
    <meta name="referrer" content="always" />
    <title>Webkit Webview test</title>
    <script type="text/javascript">

        function change_span_id(v = '') {
            //alert("test")
            document.getElementById('span_id').innerHTML = 'test' + v + gtkValue
            return v
        }

        function native_add(num) {
            //调用自定义添加的js接口
            i = GtkNative.add(num)
            document.getElementById('add').innerHTML = i
        }

        function send2Gtk() {
            e = document.getElementById('msg')
            window.webkit.messageHandlers.msgToNative.postMessage(e.value)
        }

        async function send2GtkReply() {
            e = document.getElementById('msgReply')
            // 调用自定义添加的js接口，并获取返回值
            res = await window.webkit.messageHandlers.msgToNativeReply.postMessage(e.value)
            document.getElementById('span_id').innerHTML = res
        }
    </script>
</head>

<body>
    <span>words for test: </span><span id="span_id"></span>
    <br />
    <button onclick="change_span_id()">change span id</button>
    <br />
    <span>Native add: </span><span id='add'></span>
    <br />
    <button onclick="native_add(2)">Native Add</button>
    <br />
    <input type="text" id="msg" />
    <br />
    <button onclick="send2Gtk()">Send to Native</button>
    <br />
    <input type="text" id="msgReply" />
    <br />
    <button onclick="send2GtkReply()">Send to Native Wait Reply</button>
</body>

</html>

<!DOCTYPE html>

<head>

<title>Webkit Webview test</title>

function change_span_id(v = '') {

//alert("test")

document.getElementById('span_id').innerHTML = 'test' + v + gtkValue

return v

}

function native_add(num) {

//调用自定义添加的js接口

i = GtkNative.add(num)

document.getElementById('add').innerHTML = i

}

function send2Gtk() {

e = document.getElementById('msg')

window.webkit.messageHandlers.msgToNative.postMessage(e.value)

}

async function send2GtkReply() {

e = document.getElementById('msgReply')

// 调用自定义添加的js接口，并获取返回值

res = await window.webkit.messageHandlers.msgToNativeReply.postMessage(e.value)

document.getElementById('span_id').innerHTML = res

}

</script>

</head>

<body>

<span>words for test: </span><span id="span_id"></span>

<br />

<button onclick="change_span_id()">change span id</button>

<br />

<span>Native add: </span><span id='add'></span>

<br />

<button onclick="native_add(2)">Native Add</button>

<br />

<br />

<button onclick="send2Gtk()">Send to Native</button>

<br />

<br />

<button onclick="send2GtkReply()">Send to Native Wait Reply</button>

</body>

</html>

示例运行

安装依赖：

$ sudo apt install libwebkit2gtk-4.1-doc libwebkit2gtk-4.1-dev libgtk-3-dev

1	$ sudo apt install libwebkit2gtk-4.1-doc libwebkit2gtk-4.1-dev libgtk-3-dev

把webviewgtk.c，web_exten.c，webview.html 放在同一目录下。

编译程序：

$ gcc web_exten.c -o libweb_exten.so -shared -Wl,-soname,libweb_exten.so -D_GNU_SOURCE -g3 -Wall `pkg-config --cflags --libs webkit2gtk-4.1`

$ gcc webviewgtk.c -o webviewgtk -D_GNU_SOURCE -g3 -Wall `pkg-config --cflags --libs webkit2gtk-4.1`

$ gcc web_exten.c -o libweb_exten.so -shared -Wl,-soname,libweb_exten.so -D_GNU_SOURCE -g3 -Wall `pkg-config --cflags --libs webkit2gtk-4.1`

$ gcc webviewgtk.c -o webviewgtk -D_GNU_SOURCE -g3 -Wall `pkg-config --cflags --libs webkit2gtk-4.1`

运行程序：

$ ./webviewgtk

1	$ ./webviewgtk

日期: 2025 年 3 月 5 日

Gtk应用内嵌网页与原生代码交互方法

前置条件

内容详情

Gtk嵌入网页Demo程序

Web Extension Demo

示例运行

参考链接

应用内嵌WebKitGTK报错“Unacceptable TLS certificate”

参考链接

2025 年 3 月
一	二	三	四	五	六	日
					1	2
3	4	5	6	7	8	9
10	11	12	13	14	15	16
17	18	19	20	21	22	23
24	25	26	27	28	29	30
31
